Power MOSFET

SNM6N80CActive

The SNM6N80C N-channel Mosfet, utilizing the TO-220C package, manufactured through Semiware's advanced technology. It is particularly suitable for efficient switching DC/DC converters and switching mode power supplies.

Datasheet Inquire Now

Electrical Parameters

Part Number SNM6N80C

Package TO-220C

AEC-Q101 QualifiedNo

Channel Type N

With ESD No

VDS [Max] (V) 800

VGS [Max] (V) ±30

ID [Max] (A) 6

RDS(ON)@10V
[Typ] (Ω) 2

RDS(ON)@10V
[Max] (Ω) 2.5

RDS(ON)@4.5V
[Typ] (Ω) -

RDS(ON)@4.5V
[Max] (Ω) -

RDS(ON)@2.5V
[Typ] (Ω) -

RDS(ON)@2.5V
[Max] (Ω) -

PD [Max] (W) 140

TJ (°C) 150

Status Active

Product Features

Low Gate Charge Low Crss Fast Switching
