Voltage Regulator Diode

BZT52C16Active

The BZT52C16 is a 16V Zener diode in a compact SOD-123 surface-mount package. It provides reliable voltage regulation and transient protection for a wide range of applications,including consumer electronics,power management,and portable devices.

Datasheet Inquire Now

Electrical Parameters

Part Number BZT52C16

Package SOD-123

AEC-Q101 Qualified No

VZ [Nom] (V) 16

VZ [Min] (V) 15.3

VZ [Max] (V) 17.1

IZT (mA) 5

PD [Max] (W) 0.5

VF [Max] (V) 0.9

IR [max] (uA) 0.1

TJ (°C) -65~+165

Status Active

Product Features

Planar Die Construction 500 mW Power Dissipation on Ceramic PCB Operating Temperature Range: -65°C to +165°C SOD-123 Package Ideally Suited for Automated Assembly Processes Low Leakage Current BZT52C16 RoHS Compliant
